QNAP NAS

Overview​

QNAP is a well-grounded target: UltraTorrent is deployed on it and the quirks below are real ones the project has hit.

A QNAP is a Docker host with three sharp edges:

  1. QNAP's own admin web UI already owns port 8080. You must remap UltraTorrent's.
  2. The docker binary is not on your PATH by default after SSH'ing in. This is the single most confusing QNAP gotcha.
  3. Older Container Station versions ship the legacy docker-compose (hyphen) instead of docker compose (space).

Everything else is the Docker Compose guide, verbatim.

Watch this tutorial

Video coming soon.

Prerequisites​

  • A QNAP NAS that supports Container Station (most models from the last several years).
  • An administrator account.
  • Container Station installed — App Center → search → Install. This is what provides Docker.
  • The NAS's IP address, e.g. 192.168.1.50.
  • About 2 GB of free RAM and 10–15 minutes.

Requirements​

MinimumComfortable
CPUx86-64 or ARM64, 2 cores4 cores
RAM2 GB free during the build4 GB+
Disk~3 GB for images + your downloads—
ARM QNAP models

ARM-based QNAPs build fine (the base images are multi-arch) but slowly, and the low-RAM models will struggle with the build. If the build gets killed, that is memory, not architecture.

Ports​

PortOwnerNotes
8080QNAP's own admin web UIHard conflict. Remap UltraTorrent
18080Your UltraTorrent UISuggested free port
9696Prowlarr, if you enable that profileChange with PROWLARR_PORT if taken
# .env
FRONTEND_PORT=18080

Then open http://<NAS-IP>:18080.

Do not remap ports with an override file

Compose appends ports: entries, so an override adds a second mapping while the original 8080 one survives and still clashes with QTS. Change FRONTEND_PORT in .env.

Volumes​

QNAP shares live under /share/. Container Station creates a Container share:

PathUse
/share/ContainerWhere the source tree goes
/share/DownloadThe stock QNAP downloads share — a good target for your media
# docker-compose.override.yml
volumes:
  downloads:
    driver: local
    driver_opts:
      type: none
      o: bind
      device: /share/Download
Your share path may differ

Some QNAP models expose shares as /share/CACHEDEV1_DATA/<Share> with /share/<Share> as a symlink. If a bind mount misbehaves, use the full CACHEDEV path. Check with ls -l /share/.

Permissions​

Downloaded files are owned by uid 1000 by default — the app's internal user. Everything inside UltraTorrent works with that.

To also manage those files from your QNAP login over SMB, set the share's permissions to allow your NAS user. If the folder belongs to another app, set PUID/PGID to that app's user instead of chowning it — see Permissions.

Network​

Step-by-step​

1. Install Container Station​

App Center → search Container Station → Install. This is what gives the NAS Docker.

Container Station in the QNAP App Center

Screenshot needed

QNAP App Center showing Container Station with its Install / Open button.

2. Enable SSH​

Control Panel → Telnet / SSH → tick Allow SSH connection → Apply.

Turn SSH back off afterwards

You need it for the build and the one-time seed. Disable it again once UltraTorrent is running.

3. Connect​

ssh admin@192.168.1.50

The password stays invisible as you type — that is normal. First connection asks "are you sure you want to continue" → type yes.

4. Find docker — the QNAP gotcha​

Try it:

docker --version

If that says command not found — which is the normal state on QNAP — Container Station's Docker binaries are installed but not on your login PATH. Locate and add them:

# Find where Container Station put them (the path contains the app's install dir):
ls -d /share/*/.qpkg/container-station/usr/bin 2>/dev/null

# Add it to PATH for this session:
export PATH="$(ls -d /share/*/.qpkg/container-station/usr/bin | head -1):$PATH"

docker --version          # should now print a version
docker compose version    # v2.x, if your Container Station is recent enough
This path is version-dependent

The exact location of the Container Station binaries has moved between QTS releases. The ls -d glob above finds it on current versions; on older ones look under /share/CACHEDEV1_DATA/.qpkg/container-station/. If neither hits, find / -name docker -type f 2>/dev/null | head will.

To make it stick across logins, append the export PATH=... line to ~/.profile.

5. docker compose vs docker-compose​

Newer Container Station ships Compose v2 (docker compose, a space). Older ones ship only the legacy docker-compose (a hyphen).

docker compose version      # try this first
docker-compose version      # fall back to this

Use whichever one works for every command below. They accept the same flags here.

6. Get the source​

cd /share/Container
git clone https://github.com/damirabal/ultratorrent-core.git
cd ultratorrent-core

No git? On your own computer, open the project's GitHub page → Code → Download ZIP → unzip → copy the ultratorrent-core folder into the Container share using File Station or over SMB. Then cd /share/Container/ultratorrent-core.

7. Configure .env​

cp .env.example .env

# Auto-fill the three long random keys (paste this whole block as-is):
for k in JWT_ACCESS_SECRET JWT_REFRESH_SECRET ENCRYPTION_KEY; do
  sed -i "s|^$k=.*|$k=$(openssl rand -base64 48 | tr -d '\n')|" .env
done

nano .env

Set:

POSTGRES_PASSWORD=lettersAndNumbers123    # letters + numbers ONLY, no symbols
ADMIN_PASSWORD=the-password-you-log-in-with
FRONTEND_PORT=18080                       # 8080 belongs to QTS

Save and exit nano: Ctrl+O, Enter, Ctrl+X.

8. Send downloads to a share​

nano docker-compose.override.yml
volumes:
  downloads:
    driver: local
    driver_opts:
      type: none
      o: bind
      device: /share/Download        # must already exist

9. Build and start​

docker compose --profile rtorrent up -d --build
# older Container Station:
# docker-compose --profile rtorrent up -d --build

The first build takes several minutes. Let it finish.

10. Seed the database — once​

docker compose exec backend npx prisma db seed

11. Log in and add the engine​

Open http://<NAS-IP>:18080.

  • Username: admin (a username, not an email)
  • Password: your ADMIN_PASSWORD

Infrastructure → Engines → Add engine:

FieldValue
ClientrTorrent
ConnectionSCGI over TCP
Hostrtorrent
Port5000
Default engineOn

Test connection → Connected → Add engine.

Then Settings → Default Root Path → /downloads.

The GUI route​

You can paste the contents of docker-compose.yml into Container Station → Applications → Create.

The SSH route is more reliable for the first install

The GUI struggles with the one-time --build and cannot easily run the seed. Use SSH for the install, then Container Station for day-to-day start/stop/logs.

Container Station Applications view with the UltraTorrent stack running

Screenshot needed

Container Station → Applications, showing the ultratorrent-core application with its containers running.

Verification​

docker compose ps
curl -s http://localhost:18080/api/system/live
curl -s http://localhost:18080/api/system/version
NAME                       STATUS                    PORTS
ultratorrent-backend-1     Up 3 minutes (healthy)    4000/tcp
ultratorrent-frontend-1    Up 3 minutes (healthy)    0.0.0.0:18080->8080/tcp
ultratorrent-postgres-1    Up 3 minutes (healthy)    5432/tcp
ultratorrent-redis-1       Up 3 minutes (healthy)    6379/tcp
ultratorrent-rtorrent-1    Up 3 minutes (healthy)    5000/tcp

A completed download should appear in /share/Download and be visible in File Station.

Reverse proxy​

QNAP does not ship a general-purpose reverse proxy that is pleasant to use for this. Two workable options:

  1. The bundled Caddy profile — docker compose --profile proxy up -d, with your domain in deploy/Caddyfile. Requires ports 80/443 to be free on the NAS, which on QTS they often are not.
  2. A reverse proxy elsewhere on your LAN (a Linux box, a router, Nginx Proxy Manager) pointing at http://<NAS-IP>:18080.

Either way, the WebSocket upgrade headers are mandatory. See Reverse proxy.

Community-verified

QTS's own "Web Server" / virtual-host features are not a supported way to front UltraTorrent, and this project does not test them. Use one of the two options above.

HTTPS​

Simplest: put the TLS terminator on a different machine, or use the bundled Caddy profile if 80/443 are actually free. See TLS.

Updates​

Over SSH (remember the PATH export if you did not persist it):

cd /share/Container/ultratorrent-core
docker compose exec -T postgres pg_dump -U ultratorrent ultratorrent > backup-$(date +%F).sql
git pull
docker compose --profile rtorrent up -d --build
docker compose exec backend npx prisma db seed

Deployed via Container Station? Update the source folder first, then use the app's Rebuild action, and run the seed over SSH.

Full procedure and rollback: Upgrading.

Backups​

  • Database: pg_dump into a share that Hybrid Backup Sync already covers.
  • .env: copy it there too.
  • Downloads: on /share/Download, so your existing QNAP backup jobs already see them.

See Backup & restore.

Troubleshooting​

SymptomCauseFix
docker: command not found after SSHContainer Station's binaries are not on PATH — the classic QNAP gotchaexport PATH="$(ls -d /share/*/.qpkg/container-station/usr/bin | head -1):$PATH" — see above
docker compose → command not found, but docker worksOlder Container Station ships only the legacy binaryUse docker-compose (hyphen)
The UI will not load / port conflictQTS's own admin UI owns 8080Set FRONTEND_PORT=18080 in .env and re-run up -d. Do not use an override — Compose appends ports
Bind mount fails: "no such file or directory"The share path is wrongTry the full path: /share/CACHEDEV1_DATA/Download. Check with ls -l /share/
Build is killed part-wayThe NAS ran out of RAMThe build needs ~2 GB free. Stop other apps, add RAM, or build elsewhere
Cannot reach the UI from another deviceQNAP firewall / access protectionControl Panel → Security — allow the port on your LAN
Downloads are root-ownedThe privilege drop fell back to rootCheck docker compose logs rtorrent | head. Ensure cap_add: ["SETUID","SETGID"] is present on the rtorrent service
rTorrent restarts periodicallyThe known upstream rTorrent 0.9.8 crash — worse with more active torrentsNothing is lost (it reloads its session). Reduce active torrents, or use the qBittorrent profile
Container Station "Applications" import fails on --buildThe GUI is not good at building from sourceDo the first build over SSH

More: Troubleshooting.

Best practices​

  • Persist the PATH fix in ~/.profile — you will need docker again at upgrade time.
  • Always use FRONTEND_PORT=18080 (or another free port). 8080 is not negotiable on QTS.
  • Put downloads on /share/Download so File Station, SMB and Hybrid Backup Sync all see them.
  • Turn SSH back off once installed.
  • Let Hybrid Backup Sync cover the pg_dump output rather than inventing a second backup system.
  • Do the first build over SSH, then manage day-to-day from Container Station.
  • Prefer qBittorrent if you plan to run hundreds of torrents.

FAQ​

Why can't I just use port 8080? QTS's own admin web UI is on it. There is no way around that but to move UltraTorrent.

Do I have to use SSH? For the first install, effectively yes — --build and the seed step both want a shell.

Will it conflict with QNAP's Download Station? Not on ports, but do not point two BitTorrent clients at the same folder. Give UltraTorrent its own.

docker disappears every time I log in — is something wrong? No. Container Station's binaries just are not on the default PATH. Add the export PATH=... line to ~/.profile.

Does it work on ARM QNAPs? Yes — the base images are multi-arch. The build is slower and needs the same ~2 GB of RAM.

Checklist​

  • Container Station installed
  • SSH temporarily enabled
  • docker --version works (PATH export applied, and persisted in ~/.profile)
  • Established whether it is docker compose or docker-compose on this NAS
  • Source in /share/Container/ultratorrent-core
  • .env: alphanumeric POSTGRES_PASSWORD, ADMIN_PASSWORD, three distinct secrets, FRONTEND_PORT=18080
  • /share/Download bound via docker-compose.override.yml
  • Build finished; seed run once
  • Logged in at http://<NAS-IP>:18080 as admin
  • Engine added (rtorrent : 5000), Test connection green
  • Default Root Path set to /downloads
  • Downloads visible in File Station
  • SSH turned back off
  • Hybrid Backup Sync covers the pg_dump output and .env
