Synology NAS

Overview

Synology is a well-grounded target: UltraTorrent is deployed on DSM, and the quirks below are real ones the project has hit and fixed.

A Synology is just a Docker host with an unusual shell and a strong opinion about ports. The deltas are:

1. SSH is off by default, and you need sudo -i after connecting.
2. Port 8080 can clash with other DSM apps — remap it.
3. DSM strips SETUID/SETGID from containers, which would break the bundled rTorrent's privilege drop. The Compose file already re-adds them.
4. Your shares live under /volume1/….

Everything else is the Docker Compose guide, verbatim.

Watch this tutorial

Video coming soon.

Prerequisites

• A Synology NAS that supports Docker (most models from the last several years).
• An administrator account on DSM.
• Container Manager installed (older DSM calls it "Docker") — Package Center → search → Install.
• The NAS's IP address, e.g. 192.168.1.50.
• About 2 GB of free RAM and 10–15 minutes.

Requirements

	Minimum	Comfortable
CPU	x86-64 or ARM64, 2 cores	4 cores
RAM	2 GB free during the build	4 GB+
Disk	~3 GB for images + your downloads	—

Low-RAM models

Entry-level Synology units ship with 1–2 GB of RAM, and DSM itself eats a chunk of it. The image build is the memory peak — if it gets OOM-killed, add a RAM stick (many models are upgradable) or build the images on another machine.

Ports

Port	Owner	Notes
5000 / 5001	DSM itself	Untouched — UltraTorrent never publishes these
8080	Often taken by another DSM package	Remap it: set FRONTEND_PORT=18080
18080	Your UltraTorrent UI	Suggested free port

# .env
FRONTEND_PORT=18080

Then open http://<NAS-IP>:18080.

Do not remap ports with an override file

Compose appends ports: entries, so an override adds a second mapping while the original still clashes. Change FRONTEND_PORT in .env.

Volumes

DSM shares live under /volume1/. Two paths matter:

Path	Use
/volume1/docker	Where the source tree goes (Container Manager creates this share)
/volume1/downloads	Where you want the actual downloads (create the share in File Station first)

Bind the downloads volume to a real share:

# docker-compose.override.yml
volumes:
  downloads:
    driver: local
    driver_opts:
      type: none
      o: bind
      device: /volume1/downloads

Permissions

Downloaded files are owned by the app's internal user, uid 1000, by default. That is fine — everything inside UltraTorrent works.

If you also want to manage those files from your DSM login over SMB, set the share's permissions to allow your DSM user. If the folder belongs to another app (Plex, for example), do not chown it — set PUID/PGID to that app's user so the engine writes as them. See Permissions.

The DSM capability gotcha — already handled

The bundled rTorrent entrypoint starts as root, chowns the downloads volume, then drops to PUID:PGID with gosu. DSM strips SETUID and SETGID from a container's default capability set, which makes that drop fail with "operation not permitted" — and the entrypoint would fall back to running as root, leaving root-owned downloads.

docker-compose.yml already declares cap_add: ["SETUID", "SETGID"] on the rTorrent service, restoring Docker's default and letting the privilege drop work. You do not need to do anything — but if you see cannot switch to 1000:1000 (CAP_SETUID/CAP_SETGID unavailable) — running as root in the rTorrent logs, that is what happened, and it means those cap_add lines were lost from your Compose file.

Network

Note that rTorrent's SCGI port is also 5000 — but it lives inside the Docker network and is never published, so it cannot collide with DSM's own port 5000.

Step-by-step

1. Install Container Manager

Package Center → search Container Manager → Install. (On older DSM it is called Docker.)

Screenshot needed

Synology Package Center with Container Manager shown, and its Install/Open button.

2. Enable SSH

Control Panel → Terminal & SNMP → Enable SSH service → Apply.

Turn SSH back off afterwards

You need it for the build and the one-time seed. Once UltraTorrent is running, disabling SSH again is good hygiene.

3. Connect and become root

Windows

Open Windows Terminal or PowerShell (both built in):

ssh admin@192.168.1.50

macOS / Linux

ssh admin@192.168.1.50

Type your DSM admin password — it stays invisible as you type, which is normal. First connection asks "are you sure you want to continue" → type yes.

Then, on Synology specifically, become root:

sudo -i

Enter the password again. Your prompt now ends in #. Everything below assumes you did this — DSM's Docker socket is root-only.

4. Get the source

cd /volume1/docker
git clone https://github.com/damirabal/ultratorrent-core.git
cd ultratorrent-core

No git on your DSM? On your own computer, open the project's GitHub page → Code → Download ZIP → unzip → copy the ultratorrent-core folder into the docker share with File Station or over SMB. Then cd /volume1/docker/ultratorrent-core.

5. Configure .env

cp .env.example .env

# Auto-fill the three long random keys (paste this whole block as-is):
for k in JWT_ACCESS_SECRET JWT_REFRESH_SECRET ENCRYPTION_KEY; do
  sed -i "s|^$k=.*|$k=$(openssl rand -base64 48 | tr -d '\n')|" .env
done

nano .env

Set these three lines:

POSTGRES_PASSWORD=lettersAndNumbers123    # letters + numbers ONLY, no symbols
ADMIN_PASSWORD=the-password-you-log-in-with
FRONTEND_PORT=18080

Save and exit nano: Ctrl+O, Enter, then Ctrl+X.

POSTGRES_PASSWORD is the database's private password (you will rarely see it again). ADMIN_PASSWORD is what you type to log in — pick a good one and remember it.

6. Send downloads to a DSM share

Create the share in File Station first (e.g. a downloads shared folder → /volume1/downloads). Then:

nano docker-compose.override.yml

volumes:
  downloads:
    driver: local
    driver_opts:
      type: none
      o: bind
      device: /volume1/downloads

Save and exit. The folder must already exist or the bind fails.

7. Build and start

docker compose --profile rtorrent up -d --build

The first build takes several minutes. Let it finish.

8. Seed the database — once

docker compose exec backend npx prisma db seed

9. Log in and add the engine

Open http://<NAS-IP>:18080.

• Username: admin (a username, not an email)
• Password: your ADMIN_PASSWORD

Then Infrastructure → Engines → Add engine:

Field	Value
Client	rTorrent
Connection	SCGI over TCP
Host	rtorrent
Port	5000
Default engine	On

Test connection → Connected → Add engine. The Torrents page will now load.

Finally, Settings → Default Root Path → /downloads.

The GUI route (Container Manager Project)

Prefer clicking to typing? Container Manager → Project → Create → point it at the ultratorrent-core folder; it reads docker-compose.yml for you.

You still need the one-time seed. Either over SSH, or: open the backend container in Container Manager, go to its Terminal tab, and run npx prisma db seed there.

Screenshot needed

Container Manager → Project → Create, with the path set to /volume1/docker/ultratorrent-core and the detected docker-compose.yml.

The SSH route is more reliable for the first install

The one-time --build and the seed step are both easier over SSH. Use the GUI afterwards for day-to-day start/stop/logs.

Verification

docker compose ps
curl -s http://localhost:18080/api/system/live
curl -s http://localhost:18080/api/system/version

NAME                       STATUS                    PORTS
ultratorrent-backend-1     Up 3 minutes (healthy)    4000/tcp
ultratorrent-frontend-1    Up 3 minutes (healthy)    0.0.0.0:18080->8080/tcp
ultratorrent-postgres-1    Up 3 minutes (healthy)    5432/tcp
ultratorrent-redis-1       Up 3 minutes (healthy)    6379/tcp
ultratorrent-rtorrent-1    Up 3 minutes (healthy)    5000/tcp

Confirm the privilege drop worked (this is the DSM-specific check):

docker compose logs rtorrent | head -20

You should not see cannot switch to 1000:1000 … running as root. And a completed download should land in /volume1/downloads owned by 1000:1000 — not root:

ls -ln /volume1/downloads

Reverse proxy

DSM ships Application Portal → Reverse Proxy, which can front UltraTorrent with a hostname and a DSM-managed certificate.

Create a rule:

Field	Value
Source protocol / hostname / port	HTTPS · torrents.example.com · 443
Destination protocol / hostname / port	HTTP · localhost · 18080

Then — the part everyone forgets: open the rule's Custom Header tab and click Create → WebSocket. DSM inserts the Upgrade and Connection headers for you.

Without the WebSocket header preset, the UI never updates

It loads, it logs in, and then progress bars sit still forever. See Reverse proxy.

Screenshot needed

DSM Control Panel → Login Portal → Advanced → Reverse Proxy, the rule's Custom Header tab, showing the Create → WebSocket preset applied.

Community-verified

The DSM reverse-proxy flow above is standard across recent DSM versions, but the menu path moved between DSM 6 and DSM 7 (Application Portal → Login Portal). Adjust to your version.

HTTPS

DSM can obtain a Let's Encrypt certificate for you (Control Panel → Security → Certificate) and attach it to the reverse-proxy rule. That is the path of least resistance on a Synology.

Alternatives (Caddy, Traefik, DNS-01 for a LAN-only NAS): TLS.

Updates

Over SSH (as root):

cd /volume1/docker/ultratorrent-core
docker compose exec -T postgres pg_dump -U ultratorrent ultratorrent > backup-$(date +%F).sql
git pull
docker compose --profile rtorrent up -d --build
docker compose exec backend npx prisma db seed

Deployed via the GUI? Update the source folder first, then Project → Build in Container Manager, and run the seed from the backend container's Terminal tab.

Full procedure and rollback: Upgrading.

Backups

• Database: docker compose exec -T postgres pg_dump … into a share that Hyper Backup already covers.
• .env: copy it somewhere Hyper Backup covers too.
• Downloads: they are on /volume1/downloads, so your existing DSM backup jobs already see them.

See Backup & restore.

Troubleshooting

Symptom	Cause	Fix
permission denied running docker	You forgot sudo -i	Run sudo -i after connecting — DSM's Docker socket is root-only
Web UI port conflict / page will not load	Another DSM package owns 8080	Set FRONTEND_PORT=18080 in .env and re-run up -d. Do not use an override — Compose appends ports
Downloads are owned by root	The SETUID/SETGID capabilities were stripped and the privilege drop fell back to root	Confirm cap_add: ["SETUID","SETGID"] is still on the rtorrent service in docker-compose.yml, then recreate it. Check with docker compose logs rtorrent | head
Build is killed part-way	DSM ran out of RAM	The build needs ~2 GB free. Stop other packages, add RAM, or build elsewhere
docker compose → command not found	Older Container Manager ships the legacy binary	Try docker-compose (hyphen)
Bind mount fails: "no such file or directory"	/volume1/downloads does not exist	Create the shared folder in File Station first
Cannot reach the UI from another device	DSM firewall	Control Panel → Security → Firewall — allow the port on your LAN
rTorrent restarts periodically	The known upstream rTorrent 0.9.8 crash — worse with more active torrents	Nothing is lost (it reloads its session). Reduce active torrents, or use the qBittorrent profile
Everything works, but the live UI is frozen behind DSM's reverse proxy	The WebSocket custom header is missing	Add the WebSocket preset to the rule's Custom Header tab

More: Troubleshooting.

Best practices

• Turn SSH back off once you are done installing.
• Remap the UI port (18080) rather than fighting DSM for 8080.
• Put downloads on a real share (/volume1/downloads) so File Station, SMB and Hyper Backup all see them.
• Do not run UltraTorrent on the same volume as DSM's system partition if you can avoid it.
• Let Hyper Backup cover the pg_dump output — do not invent a second backup system.
• Keep cap_add: ["SETUID","SETGID"] on the rTorrent service. It exists specifically because of DSM.
• Use DSM's reverse proxy + certificate if you want HTTPS — and remember the WebSocket header.
• Prefer qBittorrent if you plan to run hundreds of torrents on a NAS.

FAQ

Do I have to use SSH? For the first install, effectively yes — the --build and the seed step are far easier there. Day-to-day management can be entirely GUI.

Will this conflict with Synology Download Station? Not on ports (UltraTorrent's are separate), but two BitTorrent clients writing the same folder is a bad idea. Give UltraTorrent its own downloads share.

Does it clash with DSM on port 5000? No. rTorrent's SCGI 5000 is inside the Docker network and never published to the host.

Can I use my existing Download Station / Transmission? Not as an engine — UltraTorrent speaks rTorrent (SCGI/XML-RPC) and qBittorrent (Web API). See Engines.

Which Synology models work? Any that can install Container Manager and give you ~2 GB of free RAM for the build. ARM64 models build too, just slower.

Checklist

• Container Manager installed
• SSH temporarily enabled
• Connected and ran sudo -i
• Source in /volume1/docker/ultratorrent-core
• .env: alphanumeric POSTGRES_PASSWORD, ADMIN_PASSWORD, three distinct secrets, FRONTEND_PORT=18080
• /volume1/downloads share created and bound via docker-compose.override.yml
• docker compose --profile rtorrent up -d --build finished
• Seed run once
• docker compose logs rtorrent shows no "running as root" fallback
• Logged in at http://<NAS-IP>:18080 as admin
• Engine added (rtorrent : 5000), Test connection green
• Default Root Path set to /downloads
• Downloads landing in /volume1/downloads with the expected owner
• SSH turned back off
• Hyper Backup covers the pg_dump output and .env
