Unraid

Overview

Unraid is a Docker host with a very good web UI and one important constraint for us: UltraTorrent is a multi-container Compose stack, not a single container, and it builds from source — so it does not fit Unraid's classic "Add Container" / Community Apps template model.

The way to run it is Docker Compose, via the Compose Manager plugin (or plain SSH).

Community-verified

Unraid is not one of this project's own deployment targets. Everything below is the standard Unraid Compose workflow applied to UltraTorrent's documented stack — the UltraTorrent parts are grounded in the repo, the Unraid parts follow Unraid's conventions. Verify against your Unraid version, and please report corrections.

Watch this tutorial

Video coming soon.

Prerequisites

Unraid 6.10+ with the array started.
Docker Compose Manager plugin (Community Applications → Apps → search "Compose") — or just SSH, which Unraid enables by default.
~2 GB free RAM for the build.

Requirements

	Minimum	Comfortable
CPU	2 cores	4 cores
RAM	2 GB free during the build	4 GB+
Disk	~3 GB on the cache/appdata pool	plus your media array

Ports

Unraid's own web UI defaults to 80 (and 443). It does not use 8080 — so FRONTEND_PORT=8080 is usually fine. Check anyway, because other containers commonly grab it:

ss -tlnp | grep :8080

If it is taken: FRONTEND_PORT=18080 in .env.

The bundled Caddy proxy profile wants 80 and 443, which Unraid's own UI holds. Do not enable that profile unless you have moved Unraid's UI ports (Settings → Management Access).

Volumes

Unraid convention:

Path	Use
`/boot/config/plugins/compose.manager/projects/ultratorrent/`	Where Compose Manager keeps a project (if you use the plugin)
`/mnt/user/appdata/ultratorrent/`	Persistent app state — put the source tree and `.env` here
`/mnt/user/downloads/`	Your media share

Bind downloads to the share:

# docker-compose.override.yml
volumes:
  downloads:
    driver: local
    driver_opts:
      type: none
      o: bind
      device: /mnt/user/downloads

Use /mnt/user/..., not /mnt/cache/... or /mnt/disk1/...

Mixing them for the same data is the classic Unraid way to corrupt a share. Pick the user share and stay on it.

Permissions

Unraid's convention is nobody:users = uid 99, gid 100, not the 1000:1000 UltraTorrent defaults. Two choices:

Option A — adopt Unraid's convention (recommended if other Unraid containers share the folder):

# .env
PUID=99
PGID=100

The engine then writes downloads as nobody:users, matching every other Unraid container.

Option B — keep 1000:1000 and chown the download share:

chown -R 1000:1000 /mnt/user/downloads

Do not do this if Plex/Jellyfin/Sonarr also write there.

The backend still runs as uid 1000

Only the engine honours PUID/PGID. The backend container is fixed at uid 1000, so the in-app File Manager's write actions on a nobody:users folder need the group added:

# docker-compose.override.yml
services:
  backend:
    group_add: ["100"]      # the `users` group

Downloading works either way; this only affects File Manager writes. See Permissions.

Network

Step-by-step

Compose Manager plugin
SSH (simplest)

1. Install the plugin

Apps (Community Applications) → search Compose Manager → Install.

2. Get the source onto the array

Compose Manager pastes a docker-compose.yml, but UltraTorrent builds from source — so the build context (the whole repo) has to be on disk. Do this over SSH:

mkdir -p /mnt/user/appdata/ultratorrent
cd /mnt/user/appdata/ultratorrent
git clone https://github.com/damirabal/ultratorrent-core.git
cd ultratorrent-core

3. Add the project

Docker tab → Compose → Add New Stack → ultratorrent, then set its directory to /mnt/user/appdata/ultratorrent/ultratorrent-core so it picks up the real docker-compose.yml and .env.

4. Configure and build

.env and the first --build are still shell work — continue in the SSH tab below, then use the plugin's Compose Up / Compose Down buttons day to day.

Compose Manager on the Unraid Docker tab with the UltraTorrent stack

Screenshot needed

Unraid Docker tab, Compose Manager section, showing the ultratorrent stack with Compose Up / Down / Update buttons.

1. SSH in

ssh root@tower.local

2. Get the source

mkdir -p /mnt/user/appdata/ultratorrent
cd /mnt/user/appdata/ultratorrent
git clone https://github.com/damirabal/ultratorrent-core.git
cd ultratorrent-core

3. Configure

cp .env.example .env
for k in JWT_ACCESS_SECRET JWT_REFRESH_SECRET ENCRYPTION_KEY; do
  sed -i "s|^$k=.*|$k=$(openssl rand -base64 48 | tr -d '\n')|" .env
done
nano .env

POSTGRES_PASSWORD=lettersAndNumbers123
ADMIN_PASSWORD=the-password-you-log-in-with
FRONTEND_PORT=8080          # or 18080 if something else has it
PUID=99                     # Unraid's `nobody`
PGID=100                    # Unraid's `users`

4. Bind downloads

nano docker-compose.override.yml

volumes:
  downloads:
    driver: local
    driver_opts:
      type: none
      o: bind
      device: /mnt/user/downloads
services:
  backend:
    group_add: ["100"]      # so the File Manager can write there too

5. Build, start, seed

docker compose --profile rtorrent up -d --build
docker compose exec backend npx prisma db seed

Finally: log in and add the engine

Open http://<unraid-ip>:8080, sign in as admin with your ADMIN_PASSWORD.

Infrastructure → Engines → Add engine → rTorrent · SCGI over TCP · host rtorrent · port 5000 · Default engine on → Test connection → Add engine.

Then Settings → Default Root Path → /downloads.

Verification

docker compose ps
curl -s http://localhost:8080/api/system/live

NAME                       STATUS                    PORTS
ultratorrent-backend-1     Up 2 minutes (healthy)    4000/tcp
ultratorrent-frontend-1    Up 2 minutes (healthy)    0.0.0.0:8080->8080/tcp
ultratorrent-postgres-1    Up 2 minutes (healthy)    5432/tcp
ultratorrent-redis-1       Up 2 minutes (healthy)    6379/tcp
ultratorrent-rtorrent-1    Up 2 minutes (healthy)    5000/tcp

Then check the ownership of a finished download:

ls -ln /mnt/user/downloads

With PUID=99/PGID=100, files should be 99 100 — matching every other Unraid container.

Reverse proxy

Unraid users typically already run Nginx Proxy Manager or SWAG. Point it at http://<unraid-ip>:8080 and turn on WebSocket support — see Reverse proxy. Without it the UI loads but never updates.

Do not enable UltraTorrent's bundled proxy profile on Unraid unless you have first moved the Unraid web UI off 80/443.

HTTPS

Whatever proxy you already use (NPM, SWAG) already does certificates. See TLS.

Updates

cd /mnt/user/appdata/ultratorrent/ultratorrent-core
docker compose exec -T postgres pg_dump -U ultratorrent ultratorrent > backup-$(date +%F).sql
git pull
docker compose --profile rtorrent up -d --build
docker compose exec backend npx prisma db seed

Compose Manager's Update button pulls images — but UltraTorrent's images are built locally, so it will not fetch new code. You must git pull and rebuild. See Upgrading.

Backups

Unraid's Appdata Backup plugin covers /mnt/user/appdata — put your pg_dump output and a copy of .env there and it is handled:

docker compose exec -T postgres pg_dump -U ultratorrent ultratorrent \
  > /mnt/user/appdata/ultratorrent/backup-$(date +%F).sql
cp .env /mnt/user/appdata/ultratorrent/env.bak

See Backup & restore.

Troubleshooting

Symptom	Cause	Fix
No Community Apps template for UltraTorrent	There isn't one — this is a multi-container stack built from source	Use Compose Manager or SSH
Compose Manager's Update does nothing useful	It pulls images; UltraTorrent's are built locally	`git pull` then `up -d --build`
Downloads owned by `1000:1000`, other apps cannot read them	The default `PUID`/`PGID`	Set `PUID=99`, `PGID=100` and recreate the engine container
File Manager cannot write to `/downloads`	The backend is uid 1000, the folder is `nobody:users`	`group_add: ["100"]` on the `backend` service
Bind mount fails	Path typo, or the share does not exist	Create the share first; always use `/mnt/user/...`
Data appears in two places / share weirdness	You mixed `/mnt/user`, `/mnt/cache` and `/mnt/diskN` for the same data	Use `/mnt/user/...` exclusively
Port 8080 in use	Another container took it	`FRONTEND_PORT=18080`
Bundled `proxy` profile will not start	Unraid's own UI holds 80/443	Do not use that profile; use NPM/SWAG instead
Stack does not restart after a reboot	Compose Manager auto-start not enabled	Enable auto-start on the stack (the `restart: unless-stopped` policy handles the rest)
Build OOM-killed	Under ~2 GB free RAM	Stop other containers and retry

More: Troubleshooting.

Best practices

PUID=99 / PGID=100 so downloads match Unraid's convention and your media apps can read them.
Source tree and .env under /mnt/user/appdata/ so the Appdata Backup plugin covers them.
Downloads on a /mnt/user/ share, never a raw disk or cache path.
Do not use the bundled proxy profile — you already have NPM/SWAG, and Unraid owns 80/443.
Remember Compose Manager's Update button does not update UltraTorrent. git pull + --build.
Prefer qBittorrent if you plan to run a large library.

FAQ

Why isn't there a Community Apps template? Because UltraTorrent is a five-plus-container Compose stack that builds from source — CA templates are for single, prebuilt containers.

Can I use Unraid's "Add Container" UI instead? Not practically. You would be hand-wiring Postgres, Redis, the backend, the frontend and the engine, plus a build step. Use Compose.

Do I have to use the plugin? No — plain SSH works, and Unraid ships Docker Compose.

Will it survive a reboot? Yes, provided Docker starts and the stack is set to auto-start; every service carries restart: unless-stopped.

Should downloads go on the cache pool or the array? Active downloads on the cache pool are much faster; move completed media to the array with the Mover. That is an Unraid question, not an UltraTorrent one.
