Architecture Overview

What actually runs on your machine, what talks to what, and what happens between "paste a magnet" and "Plex shows the movie".

This is the user's architecture tour

It explains the moving parts you can see, restart, and back up. If you want the engineering internals — Clean Architecture layers, provider seams, module manifests, the event bus — read Developer architecture.

Overview

UltraTorrent is a small constellation of containers. Only two of them are UltraTorrent itself; the rest are well-known infrastructure and optional companions.

Purpose

Understanding this diagram lets you answer, on your own:

• Why can't the backend reach my engine at localhost?
• What do I actually need to back up?
• Which container do I look at when something breaks?
• What is safe to expose, and what must never be?

When to use this page

Read it after Quick Start, before you put UltraTorrent anywhere near a real network, and again whenever you are debugging something that crosses a container boundary.

Prerequisites

• A running stack (see Quick Start).
• The vocabulary from Core Concepts — engine, indexer, tracker, library.
• A rough idea of what a Docker container and a Docker volume are.

---

Concepts

The two halves of UltraTorrent

	frontend	backend
What it is	A React 18 + Vite single-page app, served as static files.	A NestJS API server.
What it does	Renders the UI. Nothing else.	Everything else.
Talks to	Only the backend.	Postgres, Redis, the engine, indexers, media servers.
Published to the host	Yes — :8080 by default.	No. The frontend reaches it over the internal network.

The browser never talks to your torrent engine

This is a deliberate architectural rule and it is worth understanding. The SPA talks only to the UltraTorrent API. The API translates every request into the engine's native protocol (XML-RPC over SCGI for rTorrent, the Web API for qBittorrent) and hands back normalized, engine-agnostic data. That is why you can swap engines without any UI or rule changing, and why your engine never has to be exposed to a browser.

Every container, and what it is for

Container	Required?	Purpose	If it dies…
postgres	✅ Always	The system of record: users, roles, permissions, torrent snapshots, RSS feeds/rules, automation, API keys, the audit log, settings, and the whole Media Manager model set.	The backend cannot start. This is what you back up.
redis	✅ Always	Caching and background-job coordination.	Things get slower; state is not lost.
backend	✅ Always	The API, the WebSocket gateway, the engine sync loop, RSS polling, scheduled jobs, the media pipeline. Runs prisma migrate deploy on boot.	Nothing works. Check its logs first.
frontend	✅ Always	Serves the SPA on :8080.	The UI is unreachable; the API still works.
rtorrent	Optional (--profile rtorrent)	Bundled BitTorrent engine, SCGI on :5000.	Transfers stop; UltraTorrent keeps running.
qbittorrent	Optional (--profile qbittorrent)	Bundled BitTorrent engine, Web API on :8080 internally, published on :8081. Preferred for large libraries.	Transfers stop; UltraTorrent keeps running.
prowlarr	Optional (--profile prowlarr)	An indexer manager. Not part of UltraTorrent — UltraTorrent only links to it and searches its Torznab endpoints.	Indexer search fails; everything else works.
flaresolverr	Optional (--profile flaresolverr)	Solves Cloudflare anti-bot challenges for Prowlarr indexers that need it. Internal only.	Cloudflare-protected indexers fail.
proxy	Optional (--profile proxy)	A Caddy edge reverse proxy for TLS termination on :80/:443.	Direct-port access still works.

Only one engine is a good idea at a time, at first

You can register several engines and mark one Default. But while you are learning, run one. Two engines writing into the same /downloads tree is a fine way to confuse yourself.

Ports, at a glance

Port	Who	Published to host?	Change with
8080	frontend (the web UI)	✅ Yes	FRONTEND_PORT
4000	backend API	❌ No (internal only)	Add a ports: mapping if you need it
5432	postgres	❌ No	—
6379	redis	❌ No	—
5000	rtorrent SCGI	❌ No	—
8081	qBittorrent Web UI	✅ Yes	QBITTORRENT_PORT
9696	Prowlarr Web UI	✅ Yes	PROWLARR_PORT
8191	FlareSolverr	❌ No	—
80 / 443	Caddy proxy	✅ Yes (--profile proxy)	—

Inside the network, use container names

qbittorrent:8080, rtorrent:5000, prowlarr:9696, postgres:5432. From inside the backend container, localhost means the backend itself — never the engine. This is the #1 cause of "engine test failed".

Where your data lives

Back up postgres_data and your .env. Those two, together, are your install. Losing downloads costs you bandwidth; losing postgres_data costs you every rule, library, user and decision you ever configured.

Back up ENCRYPTION_KEY with the database

ENCRYPTION_KEY decrypts what is stored encrypted in that database — 2FA secrets, indexer API keys, media-server tokens. A database restored without its matching key has a lot of unreadable secrets in it. Keep them together. See Backup & restore.

---

Step-by-step: how a download actually flows

Follow one file all the way through. Each step names the component that owns it.

Step 1 — Something decides a release is wanted

Three doors lead into the same hallway:

Door	Who opens it	Component
You paste a magnet	You	The Torrents page → REST POST /api/torrents
An RSS rule matches	The rss_poll job (every 60s)	The RSS module
A gap gets filled	The missing-episode sweep or Search now	Indexers + Smart Download

Expected result: the backend holds a magnet or a .torrent URL, and knows the save path, category and tags to use.

Step 2 — The backend hands it to the engine

The backend calls the engine through the engine seam — one interface every engine implements. rTorrent gets XML-RPC over SCGI; qBittorrent gets its Web API.

For a .torrent URL, the backend fetches it server-side through an SSRF guard that rejects private/internal addresses unless the host is listed in SSRF_ALLOW_HOSTS.

Expected result: the engine has the torrent and starts talking to the tracker.

Step 3 — The engine transfers the data

The engine announces to the tracker, gets a peer list, and exchanges pieces. It writes into /downloads — the volume the backend also mounts.

Expected result: bytes on disk, progress climbing.

Step 4 — The sync loop notices, and your browser updates itself

A background sync service polls every engine roughly every 2 seconds, normalizes what it finds, and fans it out over the WebSocket gateway to permission-scoped rooms.

Expected result: the Torrents page updates live, with no refresh. You are not polling from the browser — the server is pushing.

Step 5 — Completion fires an event

When the sync loop sees progress cross 100%, it emits torrent.completed.

Two independent things listen:

• The automation engine — your condition/action rules.
• The media pipeline — but only if an enabled library's root path contains this torrent's save path. Arbitrary downloads are never auto-organised.

Completion is edge-triggered and backfilled

torrent.completed fires when progress crosses to 100% on a live tick. A reconcileCompleted backfill then re-evaluates torrents that are already complete but never crossed that edge — first seen complete, finished while the app was down, or a rule created after completion. A success ledger keeps it idempotent, so each rule runs once per torrent.

Step 6 — The media pipeline turns a download into a library entry

Each stage is isolated — a failure in one never aborts the rest — and each fires a media.* event your automation rules can react to.

Expected result: a correctly named file in your library, enriched with metadata and artwork, visible in your media server.

The whole thing, on one diagram

---

Examples

Trace a problem to a container in one command

docker compose logs --tail 100 backend      # rules, decisions, the API, the pipeline
docker compose logs --tail 100 qbittorrent  # transfers, tracker errors
docker compose logs --tail 100 prowlarr     # indexer search failures
docker compose logs --tail 100 postgres     # migrations, connection errors

Nine times out of ten, backend is the right first look.

Confirm the backend can actually see the engine

docker compose exec backend sh -c "getent hosts qbittorrent || getent hosts rtorrent"

If that prints nothing, they are not on the same Docker network and no engine configuration will ever work.

Confirm they share a filesystem (so hardlinks can work)

docker compose exec backend    stat -c '%d %m' /downloads
docker compose exec qbittorrent stat -c '%d %m' /downloads

Same mount point, same device → hardlinks will work.

---

Troubleshooting

Symptom	The component to look at	Why
Web UI blank / unreachable	frontend	Port conflict, or the container is not running.
UI loads but every request errors	backend	The API is down or refused to boot.
Backend refuses to boot	.env	Missing/weak/identical JWT_ACCESS_SECRET and ENCRYPTION_KEY.
Backend cannot start, DB errors	postgres	Volume corruption, or a wrong POSTGRES_PASSWORD.
Engine test fails	backend → engine networking	You used localhost, or the profile is not running.
Torrents show but never update	backend	The WebSocket did not connect — check the connection indicator in the top bar.
Indexer search returns nothing	prowlarr	The indexer is down, or blocked by Cloudflare → add FlareSolverr.
Auto-grabs silently do nothing	backend (SSRF guard)	Private-IP indexer not in SSRF_ALLOW_HOSTS.
Files organised but Plex shows nothing	the media-server integration	Wrong base URL/token, or Plex cannot see the same path.

More at Troubleshooting and Performance.

---

Tips

Health probes are public on purpose

/api/system/live and /api/system/ready need no authentication so that Docker, Kubernetes and your uptime monitor can check them. They expose no data.

Everything long-running is a background job

Scanning, metadata, artwork, subtitles, renaming, NFO generation, media-server refresh — none of it blocks an HTTP request. Each unit is persisted as a job with queued/running/completed/failed status and streams its progress over WebSocket. If a page seems to "hang", it usually is not: look for the job.

Do not publish the backend port unless you mean it

The backend is deliberately not published to the host. If you expose :4000 directly, you have exposed the API — put it behind the reverse proxy instead. See Reverse proxy and Security.

Watch this tutorial

Video coming soon.

---

FAQ

Can I use my own PostgreSQL / Redis? Yes. Point DATABASE_URL (manual installs) and REDIS_HOST / REDIS_PORT at them and drop those services from Compose. See Environment.

Can I run the engine on a different machine? Yes, if the backend can reach it over the network and the paths it reports are visible to the backend at the same paths. The second half is the hard part — that is why the bundled stack shares one volume.

Do I need Redis? Yes, in the supported deployment. It backs caching and background-job coordination.

Does UltraTorrent need an internet connection to run? The application itself, no. Metadata (TMDB), artwork and indexer search obviously do. The docs site itself is built with a local, offline search index precisely because self-hosted users may be air-gapped.

Is there an external message broker / queue? No. Background work runs in-process, persisted as jobs, with Redis for coordination — no external broker is required.

Where do I change the port the UI runs on? FRONTEND_PORT in .env, then docker compose up -d.

---

Checklist

• You can name every container in your docker compose ps output and say what it does.
• You know which port the UI is on and which ports are internal-only.
• You know that the browser never talks to the engine.
• You can explain why localhost fails inside the backend container.
• You know that postgres_data + .env (with ENCRYPTION_KEY) is what you must back up.
• You can trace a magnet all the way to a media-server refresh.
• docker compose exec backend stat -c '%d %m' /downloads matches the engine's.

Expected results

Check	Expected
curl http://localhost:8080/api/system/ready	Success.
docker compose exec backend getent hosts qbittorrent	An internal IP.
Top bar in the UI	A connected WebSocket indicator and live rates.
